- Product
- Juniper Networks SRX 5800 Services Gateway
- Features
- Modular design, firewall protection, Denial of Service attack protection, support of IPv6, haute availability, DDoS attack prevention (flooding attacks), Quality of Service (QDS), IPSec Link, 2 fans
- performance
- - Firewall throughput: 300 Gbps
- IPS throughput: 100 Gbps
- VPN throughput (IPSec): 200 Gbps
- Capacity
- - New connections per second: 450000
- Concurrent sessions: 1000000
- Data link protocol
- Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet
- Routing protocol
- OSPF, RIP-1, RIP-2, BGP, Static IP routing, OSPFv3, ECMP, Policy-basedd routing (PBR), RIPng, Bidirectional Forwarding detection (BFD), IPv4-to-IPv6 Multicast
- Algorithme de chiffrement
- DES, MD5, AES, IKE, DH, SHA-1, PKI
- Protocoles VoIP
- SDP
- Protocole network / transport
- IPSec, PPPoE, DHCP, DNS, DDNS
- Flash memory
- 4 GB
- Ports
- - 10 x 10 GB Ethernet - SFP+
- RAM
- 16 GB
- Processor
- 1 x Xeon 1.8 GHz
- Disque dur
- 128 GB SSD
- Remote management protocol
- SNMP 2, Telnet, SNMP 3, HTTP, HTTPS, SSH, CLI
- Standards compliance
- FCC Class B certified, CSA, CTR 21, VCCI Class B ITE, EN55022 class B, DOC, CS-03, UL 60950-1, EN 60950-1, le CIEM class B
- Included software
- JUNOS
- Expansion slots
- - 2 (total) / 0 (free) x Switch Control Board (SCB)
- 12 (total) / 12 (free) x Logement for extension
- Power supply
- CA 120/230 V (50/60 Hz)
- Power consumption
- 15.4 Watt
- chassis type
- Montable on rack16U
