- Product
- Juniper EX2300-24MP
- performance
- - Rate de transfert de data : 208 Gbps
- Throughput: 154 Mbps
- speed fond de panier: 80 Gbps
- Capacity
- - Files d'attente hardware QoS per port: 8
- Maximum number of sessions concurrentes: 4
- Entries ARP: 5000
- prefixedd de routes IPv4 : 512
- routes IPv4 hosts : 4096
- Routes IPv4 (multicast): 4096
- Groupes multicast layers 3 : 2048
- Entries de table voisine IPv6: 1500
- prefixedd de routes IPv6 512
- routes IPv6 hosts : 2048
- Routes IPv6 (multicast): 2048
- Filtres de output de Firewall : 256
- Filtres d'entries de Firewall : 256
- accesss Control Entries (ACEs) per ACL: 2000
- Groupes LAG: 128
- Maximum number of ports membres per LAG: 8
- Entries d'observation IGMP: 2000
- Instances VSTP : 253
- Interfaces virtuelles (VLAN): 4093
- Data link protocol
- Ethernet, Fast Ethernet, Gigabit Ethernet, HDLC, Frame Relay, PPP, MLPPP, MLFR
- Routing protocol
- OSPF, RIP-1, RIP-2, IGMPv2, IGMP, OSPFv2, PIM-SM, Static IP routing, PIM-DM, IGMPv3, OSPFv3, PIM-SSM, Static routing IPv4, Static routing IPv6, RIPng, MLDv2, MLD, CIDR
- Algorithme de chiffrement
- DES, Triple DES, MD5, IKE, SSL, SHA-1, PKI, AES 256 bits, IKEv2, SHA 256 bits
- MAC address table size
- 16000 entries
- Protocoles VoIP
- SDP
- Power Over Ethernet (PoE)
- - PoE+
- Budget PoE : 380 W
- Processor
- ARM: 1.25 GHz
- RAM
- 2 GB
- Flash memory
- 8 GB
- Remote management protocol
- SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH, SSH-2
- Ports
- - 4 x 10 Gb - SFP+
- 16 x 1000Based-T RJ-45 PoE+ - 30 W
- 8 x 100/1000/2.5G - RJ-45 PoE+
- 1 x series RJ-45 management
- Standards compliance
- EEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ad, IEEE 802.1ab (LLDP), IEEE 802.1ak, IEEE 802.3at, IEEE 802.1BR
- Included software
- JUNOS
- Expansion slots
- 0 (total) / 0 (free) x expansion Slots
- Power supply
- CA 120/230 V (50/60 Hz)
- Power consumption
- 155 Watt
- chassis type
- 1U
