- Features
- control flux, mise en miroir ports, support protocole SNTP, support protocole STP (Spanning Tree Protocol), support protocole RSTP (Rapid Spanning Tree Protocol), support protocole Multiple Spanning Tree Protocol (MSTP), support d'images extended, support LLDP, Link Aggregation Control Protocol (LACP), based d'information de management (MIB), balisage VLAN, tampon de packets 1,5 MB
- capacitys
- - Interfaces virtuelles (VLAN): 4000
- Maximum number of groupes d'aggregation: 13
- performance
- - Switching capacity: 288 Gbps
- Throughput: 428 Mpps
- Latency: 2 µs
- Remote management protocol
- SNMP 1, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH, CLI
- Ports
- - 24 x 1000Based-TX RJ-45
- 4 x LAN 10 GB SFP+
- 2 x LAN 40 GB QSFP+
- 1 x 1000Based-T RJ-45 management
- 1 x console RJ-45
- RAM
- 2 GB
- Normes de conformités
- IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.1AX
- Montable en rack
- 1U
