- Features
- control flux, auto-negotiation, mise en miroir ports, support protocole SNTP, support protocole STP (Spanning Tree Protocol), support protocole RSTP (Rapid Spanning Tree Protocol), support protocole Multiple Spanning Tree Protocol (MSTP), support d'images extended, STP Root Guard, without fans, Link Aggregation Control Protocol (LACP), client DHCP, based d'information de management (MIB), tampon de packets 512 KB, authentification 802.1x, Storm Control, Back Pressure Support, Link Aggregation, Management Information Based (MIB) II, Guest VLAN, STP BPDU Guard, management IPv6, VLAN Tagging, FortiLink Mode, MAC accesss Bypass (MAB), serveur Telnet
- capacitys
- - support de VLAN: 4000
- Groupes d'aggregation de liens: 8
- performance
- - Switching capacity: 20 Gbps
- Packet forwarding rate : 14.88 Mpps
- Latency : 4 ms
- Remote management protocol
- SNMP 1, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH, CLI
- Ports
- - 7 x 1000Based-T RJ-45
- 1 x 1000Based-T RJ-45 entries PoE
- 2 x Gigabit LAN SFP
- 1 x console RJ-45
- RAM
- 256 MB DDR3 SDRAM
- Normes de conformités
- EEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.1AX
- Montable en rack
- 1U
