- Extreme Networks VSP7400-32C-AC-R
- VSP 7400, ports QSFP28 32 x 100 Gbit/s, processor 8 cœurs, 16 GB de RAM, SSD de 128 GB, Power supply unique de 750 W CA, six fans, kit de Mounting en rack à 4 montants, flux d'air rear to l'avant
- Features
- auto-negotiation, support of ARP, support network local (LAN) virtuel, mise en miroir ports, inspection approfondie, sFlow, support protocole Multiple Spanning Tree Protocol (MSTP), Quality of Service (QDS), flux d'air avant-rear, Link Aggregation Control Protocol (LACP), Remote Switch Port Analyzer (RSPAN), Virtual Routing and Forwarding (VRF), fans replaceable hot, IPFIX, 6 fans, Shortest Path Bridging (SPB), Virtual extensible LAN (VXLAN), support IP Shortcut Routing, Rapid Reconfiguration of Spanning Tree (RSTP), Test de boucle métallique for lignes d'abonnés (MLT),VLAN based sur le port, support Virtual Service Networks (VSN),
- performance
- - Switching capacity: 6.4 Tbps
- Rate de transfert: 1.929 Mpps
- Capacity
- - support de VLAN: 4059
- Instances MSTP: 64
- Groupes MLT/LACP: 32
- Routes IPv4: 16000
- Interfaces RIP: 200
- Interfaces OSPF: 512
- Instances VRF: 256
- Entries de table voisine IPv6: 32000
- Routes IPv6: 7500
- Interfaces RIPng: 48
- Interfaces OSPFv3: 500
- CPU
- 8 Core
- RAM
- 16 GB de memory DDR4 ECC
- Disque Dur
- 128 GB SSD
- Ports
- - 32 x 100Gbit LAN QSFP28
- 1 x series (console) RJ-45 management
- 1 x 1000Based-T RJ-45 management
- 1 x micro-USB Type A stockage
OS
- Normes de conformités
- BSMI, EN 61000-3-2, SABS, EN 61000-3-3, EN55024, CB, AS/NZS 60950-1, CCC, ICES-003 class A, UL 60950-1, IEC 60950-1, EN 60950-1, KCC, CDRH, VCCI Class A, EAC, GB 9254, EN 300386 V1.6.1, RoHS 2011/65/EU, EN 55011 class A, CISPR 11 class A, WEEE 2012/19/EU, EMC 2014/30/EU, FCC CFR47 Part 15 B Class A, LVD 2014/35/EU, GB 4943.1-2011, IEC/EN 61000-4-3, IEC/EN 61000-4-5, IEC/EN 61000-4-6, IEC/EN 61000-4-8, CNS 14336-1, EN 62368-1, IEC 62368-1, IEC/EN 61000-4-11, IEC/EN 61000-4-2, EN 55032 Class A, ETSI EN 300019-2-3 V2.1.2, ETSI EN 300019-2-2 V2.1.2, NRCS, EN/ETSI 300019-2-1 v2.1.2, EN/ETSI 300753, ASTM D3580, CISPR 24:2010 Class A, ACMA RCM, CISPR 32 Class A, EN 60825-1 Class 1, CAN/CSA-C22.2 No. 62368-1, CAN/CSA-C22.2 No. 60950-1, UL 62368-1, China RoHS SJ/T 11363-2006, RoHS CNS 15663, FCC CFR21 Part 1040.10, AS/NZS CISPR 32
- Montable en rack
- 1U
