- Features
- auto-negotiation, support of ARP, support network local (LAN) virtuel, mise en miroir ports, inspection approfondie, sFlow, support protocole Multiple Spanning Tree Protocol (MSTP), Quality of Service (QDS), flux d'air avant-rear, Link Aggregation Control Protocol (LACP), Remote Switch Port Analyzer (RSPAN), Virtual Routing and Forwarding (VRF), fans replaceable hot, IPFIX, 6 fans, Shortest Path Bridging (SPB), Virtual extensible LAN (VXLAN), support IP Shortcut Routing, Rapid Reconfiguration of Spanning Tree (RSTP), Test de boucle métallique for lignes d'abonnés (MLT),VLAN based sur le port, support Virtual Service Networks (VSN),
- performance
- - Switching capacity: 7.2Tbps ( up to 21.6Tbps )
- Rate de transfert: 1.929 Mpps
- Capacity
- - ARP Entries: 64,000
- Static ARP Entries: 2000 per VRF, 10,0 0 0 per switch
- IP Interfaces: 4,059
- CLIP Interfaces: 64
- IP Routes: up to 252,000
- IP Static Routes: 2,000 per VRF, 10,0 0 0 per switch
- RIP Interfaces: 200
- OSPF Interfaces: 500 Active/ 2,000 Passive
- OSPF Areas: 12 per VRF, 80 per switch
- BGP Peers: 256
- BGP RIB Routes: 1,500,000 (Control Plane only)
- ECMP Unique Groups: 1,000
- ECMP Paths per Group: 8
- VRRP Interfaces: 512
- RSMLT Interfaces: up to 1,000
- IPv4 UDP Forwarding Entries: 1,024
- IPv4 DHCP Relay Forwarding Entries: 1,024
- IP Route Policies: 2,0 0 0 per VRF and 16,000 per switch
- VRF Instances: 512
- Ports
- - jusqu'à 48 ports de 100GBASE-QSFP28
- jusqu'à 128 ports de 40GBASE-QSFP +
- jusqu'à 192 ports 10GBASE-SFP + ou 10GBASE-T
OS
- Normes de conformités
- BSMI, EN 61000-3-2, SABS, EN 61000-3-3, EN55024, CB, AS/NZS 60950-1, CCC, ICES-003 class A, UL 60950-1, IEC 60950-1, EN 60950-1, KCC, CDRH, VCCI Class A, EAC, GB 9254, EN 300386 V1.6.1, RoHS 2011/65/EU, EN 55011 class A, CISPR 11 class A, WEEE 2012/19/EU, EMC 2014/30/EU, FCC CFR47 Part 15 B Class A, LVD 2014/35/EU, GB 4943.1-2011, IEC/EN 61000-4-3, IEC/EN 61000-4-5, IEC/EN 61000-4-6, IEC/EN 61000-4-8, CNS 14336-1, EN 62368-1, IEC 62368-1, IEC/EN 61000-4-11, IEC/EN 61000-4-2, EN 55032 Class A, ETSI EN 300019-2-3 V2.1.2, ETSI EN 300019-2-2 V2.1.2, NRCS, EN/ETSI 300019-2-1 v2.1.2, EN/ETSI 300753, ASTM D3580, CISPR 24:2010 Class A, ACMA RCM, CISPR 32 Class A, EN 60825-1 Class 1, CAN/CSA-C22.2 No. 62368-1, CAN/CSA-C22.2 No. 60950-1, UL 62368-1, China RoHS SJ/T 11363-2006, RoHS CNS 15663, FCC CFR21 Part 1040.10, AS/NZS CISPR 32
- Montable en rack
- 7U
