- Product
- Cisco Nexus 3548-XL
- Features
- control flux, support NAT, support de BOOTP, support of ARP, liaisons, support network local (LAN) virtuel, support de Syslog, control storm de Broadcast, Multicast Storm Control, support protocole RSTP (Rapid Spanning Tree Protocol), support protocole Multiple Spanning Tree Protocol (MSTP), assistance Trivial File Transfer Protocol (TFTP), assistance accesss Control List (ACL), Routing EIGRP Stub, STP Root Guard, Uni-Directional Link detection (UDLD), Rapid Per-VLAN Spanning Tree Plus (PVRST+), relais DHCP, synchronisation temporelle NTP, STP PortFast, Class of Service (CoS), Precision Time Protocol (PTP), 18MB packet buffer
- performance
- - Switching capacity : 960 Gbps
- Performances de transfert : 720 Mpps
- Capacity
- - Interfaces virtuelles (VLAN): 4096
- Entries ACL: 4096
- Routes IPv4 (multicast): 24000
- Entries de table host (IPv4): 64000
- Instances Rapid Spanning Tree Protocol: 512
- Instances Multiple Spanning Tree Protocol: 64
- Flash memory
- 2 GB
- Ram
- 16 GB
- Protocole de gestion à distance :
- SNMP 1, SNMP 2, RMON, Telnet, SNMP 3, SSH-2, CLI
- Routing protocol
- OSPF, RIP-2, BGP, EIGRP, IGMPv2, HSRP, VRRP, OSPFv2, PIM-SM, Static IP routing, IGMPv3, PIM-SSM, MSDP
- Ports
- - 48 x 10Gb SFP+
- 2 x 1000Based-T RJ-45 management
- 2 x USB
- 1 x series (RS-232)
- Standards compliance
- IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ab (LLDP)
- Included software
- Cisco NX-OS
- Power supply
- CA 120/230 V (50/60 Hz)
- chassis type
- Rack-mountable - 1U
