- Features
- support protocole Spanning Tree (STP), support liste de control d'accès (ACL), Multipath equal-cost (ECMP), spanning ports, technologie Virtual PortChannel (vPC), support MACsec, capacity de bypass, LAN extensible virtuel (VXLAN), Ethernet Virtual Private network (EVPN), Power On Auto Provisioning (POAP), 5 + 1 fans redondants, Embedded Event Manager (EEM), spanning côté port (PSE), Admission côté port (PSI), 80 MB de memory tampon system
- performance
- - Switching capacity : 25.6 Tbps
- Capacity
- -Number d'adresses MAC : 120K
-Number of routes de unicast IPv4 / IPv6: 440K / 360K
- Number d'hosts IPv4 / IPv6 : 192K / 96K
- Number of routes de multicast IPv4 :
- Jusqu'à 96K avec des groupes de 8K
- - Number of VLANS : 4K
- Number d'entries ACL : Entries 3.5 K and output 1.5 K
- Number d'instances de spanning-tree :
- Protocole MST (Multiple Spanning Tree): 64
- - Number of canaux EtherChannels : 24
- Number of ports per EtherChannel : 24
- size tampon : 70 MB
- Memory flash de démarrage : 128 GB
- Ports
- - 32 fixed 400-Gigabit-Ethernet QSFP-DD ports
- Ports de management: 2 (1 x 10/100 / 1000BASE-T and 1 x SFP + 1 Gbit / s)
- USB: 1 port
- Ports de console series RS-232: 1
- Standards compliance
- CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, AS/NZS 60950-1, ICES-003 Class A, RoHS, UL 60950-1 Second edition, GB 4943, EN 60950-1 Second edition, IEC 60950-1 Second edition, VCCI Class A, KN22 Class A, AS/NZS CISPR22:2004 Class A, EN 55022 Class A, FCC CFR47 Part 15 B Class A, CNS 13438 Class A, CAN/CSA C22.2 No. 60950-1 Second edition, EN 300386, KN 61000-4
