- Type
- Security appliance
- Type de liaison de donnée
- 10 Gigabit Ethernet, Ethernet, Fast Ethernet, Gigabit Ethernet
- Features
- Firewall protection, Load balancing, VLAN support, VPN support
- Protocole de transport
- IPSec
- Ports
- - RJ-45 X 1, Management ( 1000Bas-T) X 1
- USB 2.0 X 1
- Standards compliance
- Compliant Standards :AS/NZS 60950-1, BSMI CNS 13438 Class A, CISPR 22 Class A, CISPR 24, CSA C22.2 No. 60950-1, EN 60950-1, EN 61000-3-2, EN 61000-3-3, EN300-386, EN50082-1, EN55022 Class A, EN55024, FCC CFR47 Part 15, GB 4943, ICES-003 Class A, IEC 60950-1, UL 60950-1, VCCI Class A ITE
- Algorithme de cryptage
- AES, 3DES
- Interfaces
- - RJ-45 X 6 ( 1000Based-T)
- 4 X SFP+
- performance
- - Concurrent sessions : 4000000
- Sessions IPSec VPN : 10000
- Sessions SSL VPN : 2
- Interfaces (VLANs) : 1024
- Number of connection : 200000 connections per second
- Firewall + intrusion prevention throughput : 5 Gbps
- Throughput Firewall : 20 Gbps
- VPN throughput : 3 Gbps
- Flash memory
- 2 GB
- RAM
- 12 GB
- chassis
- - Modules installedd : 1
- Modules supportés : 2
- Power supply
- - Power supply requise : 50/60 Hz
- installed : 2, Enfichable hot
- Voltage : AC 120/230 V
